PRO DR76
The Windpower PRO DR76 is a drive axle tyre for trucks of the latest generation for use in regional transport. Its block design ensures even pressure distribution for reduced wear and a long service life. The special reinforced bead construction with steel core protects the tyre from side impact damage and maximises the life of the tyre. The PRO DR76 features high-quality cord piles which provide exceptional handling and low rolling resistance. All tyres in the Pro Series are equipped with dual-layer technology.
DESIGNED FOR:
Highway Haulage
Regional Transport
Short-Medium Haul
| Size | Ply | Pattern | Standard Rim | Permitted Rim | Max Load Single (kg) | Max Load Dual (kg) | Max Pressure Single (kPa) | Max Pressure Dual (kPa) | Tread Depth (mm) | Tread Width (mm) | LI/SS | Second LI/SS |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 315/70R22.5 | 20PR | PRODR76 | 9.00 | 9.75 | 4000 | 3350 | 900 | 900 | 21 | 280 | 156/150L | 154/150M |
| 315/60R22.5 | 20PR | PRODR76 | 9.75 | 9.00 | 3550 | 3150 | 900 | 900 | 19 | 285 | 152/148L | --- |
| 275/80R22.5 | 18PR | PRODR76 | 8.25 | 7.50 | 3450 | 3150 | 900 | 900 | 18 | 240 | 151/148L | --- |
| 265/70R19.5 | 18PR | PRODR76 | 7.50 | 8.25 | 2725 | 2575 | 830 | 830 | 16.5 | 220 | 143/141J | 146/146F |
| 245/70R19.5 | 18PR | PRODR76 | 7.50 | 6.75 | 2800 | 2650 | 900 | 900 | 17 | 213.46 | 144/142J | --- |
| 225/75R17.5 | 16PR | PRODR76 | 6.75 | 7.50 | 1850 | 1750 | 830 | 830 | 14 | 200 | 129/127M | --- |
| 205/75R17.5 | 14PR | PRODR76 | 6.00 | 5.25/6.75 | 1600 | 1500 | 760 | 760 | 14 | 180 | 124/122M | --- |
| 11R22.5 | 18PR | PRODR76 | 8.25 | 7.50 | 3150 | 2900 | 850 | 850 | 18 | 230 | 148/145J | --- |
