W747
The W747 is engineered with an aggressive tread design to deliver excellent traction and flotation characteristics. The W747’s enhanced rubber compound offers exceptional tread life and superior resistance to punctures. The W747 is designed for use on haul trucks.
DESIGNED FOR:
Haul Trucks / Transport Vehicles
Articulated Dump Trucks
Rigid Dump Trucks
| SIZE | STAR RATING | TRA CODE | MODEL | TYPE | COMPOUND | RIM | O.D. (mm) | O.W. (mm) | LI/SS | OTD (mm) | TKPH |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 18.00R33 | ★★ | E-4 | W747 | TL | B | 13.00/2.5 | 1862 | 510 | 191B | 54 | 244 |
| 18.00R33 | ★★ | E-4 | W747 | TL | A | 13.00/2.5 | 1862 | 510 | 191B | 54 | 160 |
| 18.00R33 | ★★ | E-4 | W747 | TL | A2 | 13.00/2.5 | 1862 | 510 | 191B | 54 | - |
| 18.00R33 | ★★★ | E-4 | W747 | TL | B | 13.00/2.5 | 1862 | 510 | 195B | 54 | 266 |
| 18.00R33 | ★★★ | E-4 | W747 | TL | A | 13.00/2.5 | 1862 | 510 | 195B | 54 | 170 |
| 18.00R33 | ★★★ | E-4 | W747 | TL | A2 | 13.00/2.5 | 1862 | 510 | 195B | 54 | - |
| 24.00R35 | ★★ | E-4 | W747 | TL | B | 17.00/3.5 | 2181 | 667 | 209B | 59 | 414 |
| 24.00R35 | ★★ | E-4 | W747 | TL | A | 17.00/3.5 | 2181 | 667 | 209B | 59 | 326 |
| 24.00R35 | ★★★ | E-4 | W747 | TL | B | 17.00/3.5 | 2181 | 667 | 212B | 59 | - |
| 24.00R35 | ★★★ | E-4 | W747 | TL | A | 17.00/3.5 | 2181 | 667 | 212B | 59 | - |
