WGC28
The Windpower WGC28 is an all-position tyre suited well to drive and trailer configurations on construction sites or on/off road haulage applications. It can also be used on steering axle in certain site applications. The WGC28 features rock-repelling divots, cut/chip resistant compound a rugged, reinforced carcass.
DESIGNED FOR:
On/Off Road Haulage
Concrete Mixers
Construction Vehicles
Poor conditions
Heavy Haulage Float Trailer
Fuel Transport
Mining Trucks
| Size | Ply | Pattern | Standard Rim | Permitted Rim | Max Load Single (kg) | Max Load Dual (kg) | Max Pressure Single (kPa) | Max Pressure Dual (kPa) | Tread Depth (mm) | Tread Width (mm) | LI/SS | Second LI/SS |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 445/65R22.5 | 20PR | WGC28 | 13.00 | 12.25/14.00 | 5800 | --- | 900 | --- | 16.5 | 348 | 169K | --- |
| 425/65R22.5 | 20PR | WGC28 | 12.25 | 11.75/13.00 | 5150 | --- | 830 | --- | 16.5 | 324 | 165K | --- |
| 385/65R22.5 | 20PR | WGC28 | 11.75 | 12.25 | 5000 | --- | 900 | --- | 16.8 | 297 | 164K | 158L |
| 385/55R22.5 | 20PR | WGC28 | 12.25 | 11.75 | 4250 | --- | 900 | --- | 16.5 | 306 | 158L | 160K |
| 275/70R22.5 | 18PR | WGC28 | 8.25 | 9.00 | 3150 | 2900 | 900 | 900 | 17.5 | 218 | 148/145M | --- |
| 265/70R19.5 | 18PR | WGC28 | 7.50 | 8.25 | 2725 | 2575 | 830 | 830 | 17.5 | 200 | 143/141J | -- |
| 255/70R22.5 | 16PR | WGC28 | 7.50 | 8.25 | 2500 | 2300 | 830 | 830 | 17.5 | 196 | 140/137M | 140/140L |
| 245/70R17.5 | 18PR | WGC28 | 7.50 | 6.75 | 2725 | 2575 | 900 | 900 | 16.5 | 195 | 143/141 J | 144/144F |
| 235/75R17.5 | 18PR | WGC28 | 6.75 | 7.50 | 2725 | 2575 | 900 | 900 | 16.5 | 192 | 143/141 J | --- |
| 215/75R17.5 | 18PR | WGC28 | 6.00 | 6.75 | 2180 | 2060 | 830 | 830 | 15.5 | 175 | 135/133 J | --- |
| 11R22.5 | 16PR | WGC28 | 8.25 | 7.50 | 3000 | 2725 | 830 | 830 | 20 | 210 | 146/143L | --- |
